Perfect for 36v Golf Carts
Play longer with twice the run time for your golf cart or electric vehicle, while cutting 300 lbs or more off your cart. Experience better golf cart handling, less wear & tear, and lower maintenance costs. Drop in replacement for most 36V golf carts.
Built Dakota tough, this single 36V (volt) lithium battery will help you play longer with twice the run time for your golf cart or electric vehicle, while lasting 5x longer, providing exceptional lifetime value. Built out of our legendary lithium iron phosphate (LiFePO4) cells, this battery requires no maintenance or watering, can be installed in any orientation, and can charge 5X faster then lead acid – giving you more time, and more freedom on and off the green. The best part is this single Dakota Lithium battery weighs 1/4 as much as a set of lead acid golf cart batteries, allowing you to cut 300 lbs or more off your cart. Experience better golf cart handling, less wear & tear, and lower maintenance costs. 15-20 mile range per battery, depending on cart model and average cruising speed. Link multiple batteries in parallel for up to 80+ miles of range. For carts with motor controllers >200A (amps) two batteries are required to meet the amps needed of the motor controller (for example, an EZGO TXT with a 400A motor controller would require 2 batteries and have a 40 mile driving range). Built to endure, this extended lifespan battery is backed up by an 11 year warranty. Free 36V 8A LiFePO4 charger included! This battery is a re-engineered version of DL's legendary 36V 63Ah single lithium battery but with 2X the max power (120A max continuous discharge), 50% longer lifespan, 25% smaller size (volume) and 20% less weight.
11 Year Warranty
World beating, best in class, eleven year manufacturer defect warranty.
Storage Capacity
60 ampere hours (Ah). Dakota Lithium batteries provide consistent power for all 60 amp hours. DL LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.
Voltage
36V (not intended for wiring multiple batteries in series, 36V systems only). Can be wired in parallel up to 10 units.
Energy
2,160 Watts (Wh)
Terminals
M8 bolt terminals F12 (posts that screw in). Easy to adapt to different connection needs. (Max torque 15 ft. lbs.)
Size
13”L x 6.7”W x 8.7”H (331mm x 172mm x 221 mm). Group 31 marine battery. Same case size as a standard 12V 100Ah lead acid or AGM battery.
Weight
44 lbs (20 Kg). That's 75% lighter then a lead acid battery and 25% lighter than Dakota Lithium original 36V 63Ah battery.
Battery Range
15-20 miles per battery charge. For extended range wire additional batteries in parallel, most carts can fit a max of 4 units in their battery compartment.
Lifecycles (battery lifespan)
Up to 80% capacity for 3,000 cycles in recommended conditions. The typical SLA has 500 cycles. Dakota Lithium batteries last so long that the price per use is a fraction of traditional batteries.
Operating temperature
Ideal for rugged & harsh environments. Much better than SLA or other lithium’s. -20'F min, +120'F max optimal operating temps (battery performs well down to -20'F). Avoid charging below 32'F.
Discharge
60 A max continuous, 180 A max 30 second pulse. For motor controllers with 200A-400A two parallel units are recommended. Max of 4 units in parallel.
Charge
31.5 A max, 42 V max recommended. Included is a 36v 8A LiFePO4 compatible charger (8 hour charge time). Upgrade to a 36v 18A charger for 140% faster charge time!
Includes active BMS protection
Contains a circuit that handles cell balancing, low voltage cutoff, high voltage cutoff, short circuit protection and high temperature protection for increased performance and longer life.
Certifications
All batteries are UN 38 certified. Dakota Lithium's cells are UL1642 certified and have been tested per IEC62133 standards. Meets all US & International regulations for air, ground, train, & marine transport.
Charger Included
36V 8A LiFePO4 charger included
Motor Controller Compatibility
Compatible with all 36V motors. One unit can support a motor controller rating of 200 amps. 2+ units are required for carts with a motor controller rated for >200 Amps. For example, a EZGO TXT with a 400 Amp motor controller would need two batteries wired in parallel.
